4.3.3.2.4 Reports tab
4.3.3.2.5 Flushes tab
4.3.3.2.6 Alerts tab
ELEMENT DESCRIPTION
DATA TYPE DROP-DOWN LIST THE DROP-DOWN LIST FOR SELECTION OF DATA TYPE TO BE DISPLAYED ON THE CHART.
TIME SPAN BUTTONS
CLICK DAY/WEEK/MONTH BUTTON TO SELECT DESIRED CHART'S TIME SPAN. BY DEFAULT,
LAST WEEK EVENTS ARE SHOWN.
DATES SELECTION
ENABLES SHOWING EVENTS BETWEEN TWO DATES. SELECT THE DESIRED CHART'S TIME
SPAN.
CHART
DISPLAYS THE DATA ACCORDING TO THE SELECTED PARAMETERS (DATA TYPE AND TIME
SPAN).
ELEMENT DESCRIPTION
TIME SPAN BUTTONS
CLICK DAY/WEEK/MONTH BUTTON TO SELECT DESIRED LIST'S TIME SPAN. BY DEFAULT, LAST
WEEK EVENTS ARE SHOWN.
DATES SELECTION ENABLES SHOWING EVENTS BETWEEN TWO DATES. SELECT THE DESIRED LIST'S TIME SPAN.
LIST OF FLUSHES
DISPLAY THE FLUSHES ACCORDING TO THEIR OCCURRENCE TIME AND DATE FOR SELECTED
PERIOD. FOLLOWING INFORMATION FOR EVERY FLUSH IS SHOWN:
• FLUSH CAUSE
• FLUSH DATE
• FLUSH TIME
• INLET PRESSURE BEFORE THE FLUSH
• OUTLET PRESSURE BEFORE THE FLUSH
• DP PRESSURE BEFORE THE FLUSH
• DP PRESSURE AFTER (THE DP MEASURED AFTER FLUSHING. INTERVAL BETWEEN END OF
FLUSHING AND DP MEASURING IS DETERMINED BY “IGNORE DP” PARAMETER).
ELEMENT DESCRIPTION
ACTIVE/HISTORY BUTTONS
CLICK ACTIVE BUTTON TO SEE THE LIST OF ACTIVE ALERTS FOR THE SPECIFIC
CONTROLLER.
CLICK HISTORY BUTTON TO SEE THE LIST OF ALERT MESSAGES FOR THE SPECIFIC
CONTROLLER ACCORDING TO THEIR OCCURRENCE TIME AND DATE.
TIME SPAN BUTTONS
CLICK DAY/WEEK/MONTH BUTTON TO SELECT DESIRED LIST'S TIME SPAN. BY DEFAULT, LAST
WEEK EVENTS ARE SHOWN.
DATES SELECTION ENABLES SHOWING EVENTS BETWEEN TWO DATES. SELECT THE DESIRED LIST'S TIME SPAN.
ALERTS LIST
DISPLAY THE ACTIVE ALERTS OR THE LIST OF ALERT MESSAGES ACCORDING TO THEIR
OCCURRENCE TIME AND DATE (ACTIVE/HISTORY TAB). SEE APPENDIX B. ALARMS AND
FAULTS LIST.
