Netafim AlphaDisc CLD User Manual

| AlphaDisc CLD user guide V2.0
48
4.4.3.1.1 Online status tab
4.4.3.1.2 Counters tab
4.4.3.1.3 Alerts tab
ELEMENT DESCRIPTION
THE UPPER RED/GREY LINE
DISPLAYS THE NAME OF THE SITE AND THE COMMUNICATION STATUS.
CONNECTED / DISCONNECTED.
LAST RESET AT: THE DATE OF THE LAST RESETTING OF THE COUNTERS.
DP CYCLES THE NUMBER OF FLUSH CYCLES STARTED DUE TO A DP SIGNAL.
FLUSHING INTERVAL CYCLES
THE NUMBER OF FLUSH CYCLES STARTED DUE TO THE TIME INTERVALS PROGRAM. ALSO
COUNTS THE ANTIFREEZE PROTECTION INTERVALS FLUSHES.
PRESET CYCLES THE NUMBER OF FLUSH CYCLES STARTED DUE TO THE PRESET START TIMES.
MANUAL CYCLES
THE NUMBER OF FLUSH CYCLES STARTED DUE TO A MANUAL START COMMAND ISSUED BY
THE USER.
TOTAL FLUSHING CYCLES THE TOTAL NUMBER OF FLUSH CYCLES STARTED FOR ANY REASON.
RESET BUTTON
CLICK THIS BUTTON TO RESET THE COUNTERS TO ZERO (EXCLUDING TOTAL FLUSHING
COUNTER).
ELEMENT DESCRIPTION
THE UPPER RED/GREY LINE
DISPLAYS THE NAME OF THE SITE AND THE COMMUNICATION STATUS.
CONNECTED / DISCONNECTED.
ACTIVE/HISTORY BUTTONS
CLICK ACTIVE BUTTON TO SEE THE LIST OF ACTIVE ALERTS FOR THE SPECIFIC
CONTROLLER.
CLICK HISTORY BUTTON TO SEE THE LIST OF ALERT MESSAGES FOR THE SPECIFIC
CONTROLLER ACCORDING TO THEIR OCCURRENCE TIME AND DATE.
DATES SELECTION
AVAILABLE ONLY ON HISTORY TAB. ENABLES SHOWING EVENTS BETWEEN TWO DATES. THE
ALERT MESSAGES FOR SELECTED TIME SPAN WILL BE DISPLAYED IN THE LIST.
ALERTS LIST
DISPLAY THE ACTIVE ALERTS OR THE LIST OF ALERT MESSAGES ACCORDING TO THEIR
OCCURRENCE TIME AND DATE (ACTIVE/HISTORY TAB). SEE APPENDIX B. ALARMS AND
FAULTS LIST.
ELEMENT DESCRIPTION
THE UPPER RED / GREY LINE
DISPLAYS THE NAME OF THE SITE AND THE COMMUNICATION STATUS:
CONNECTED / DISCONNECTED.
LAST CONNECTION ONLY IN OFFLINE MODE. THE LAST TIME THE CONTROLLER WAS CONNECTED.
NEXT CONNECTION ONLY IN OFFLINE MODE. THE TIME OF NEXT ATTEMPT TO CONNECT TO THE CONTROLLER.
TIME FROM LAST FLUSH ONLY IN ONLINE MODE. THE TIME SINCE THE END OF THE LAST FLUSH CYCLE.
LAST FLUSH CAUSE ONLY IN ONLINE MODE. THE TRIGGER THAT INITIATED THE LAST FLUSH.
PRESSURES – INLET THE CURRENT READING OF THE FILTER'S INLET PRESSURE.
PRESSURES – OUTLET THE CURRENT READING OF THE FILTER'S OUTLET PRESSURE.
PRESSURES – DP
THE PRESSURE DIFFERENTIAL ACROSS THE FILTER; CALCULATED BY SUBTRACTING THE
OUTLET PRESSURE FROM THE INLET PRESSURE.
MANUAL FLUSHING BUTTON ONLY IN ONLINE MODE. CLICK THIS BUTTON TO START A MANUAL FLUSH CYCLE.
