| AlphaDisc CLD user guide V2.0
49
4.4.3.1.4 Reports tab
4.4.3.1.5 History tab
4.4.3.1.6 Settings menu
Enter the Settings menu by clicking on the icon in the upper right corner of any of the 5 tabs. This menu contains
controller settings. See the list of settings with description in Appendix A. AlphaDisc™ CLD Controller Settings.
Click the setting to change it. Click Save to save changes.
ELEMENT DESCRIPTION
THE UPPER RED/GREY LINE
DISPLAYS THE NAME OF THE SITE AND THE COMMUNICATION STATUS.
CONNECTED / DISCONNECTED.
THE SECOND LINE
DISPLAYS ICONS OF THE DIFFERENT FLUSH TYPES. SELECT THE DESIRED ICONS TO BE
DISPLAYED ON THE CHART.
THE CHART WINDOW DISPLAYS THE NUMBER OF FLUSH CYCLES ACCORDING TO THE SELECTED ICONS.
TOTAL FLUSHING CYCLES THE TOTAL NUMBER OF FLUSH CYCLES CURRENTLY DISPLAYED IN THE CHART WINDOW.
THE LOWER BLACK LINE ENABLES THE USER TO SELECT THE CHART’S TIME SPAN (DAY, WEEK, MONTH).
ELEMENT DESCRIPTION
THE UPPER RED/GREY LINE
DISPLAYS THE NAME OF THE SITE AND THE COMMUNICATION STATUS.
CONNECTED / DISCONNECTED.
THE SECOND LINE ENABLES SHOWING EVENTS BETWEEN TWO DATES.
SMART FILTER
ENABLES FILTERING EVENTS ACCORDING TO THE FOUR FLUSH TYPES (FLUSHING INTERVAL,
DP, MANUAL, PRESET).
THE EVENTS LIST
DISPLAYS THE EVENTS MESSAGES ACCORDING TO THEIR OCCURRENCE TIME AND DATE.
FLUSH CAUSE, FLUSH DATE, AND FLUSH TIME ARE SHOWN IN EVERY ROW OF THE LIST.
CLICK ICON TO SEE THE FOLLOWING INFORMATION:
• INLET PRESSURE BEFORE THE FLUSH
• OUTLET PRESSURE BEFORE THE FLUSH
• DP PRESSURE BEFORE THE FLUSH
• DP PRESSURE AFTER (THE DP MEASURED AFTER FLUSHING. INTERVAL BETWEEN END OF
FLUSHING AND DP MEASURING IS DETERMINED BY “IGNORE DP” PARAMETER).
