Configuration Options
• Simplex E2712
controller-drive tray
with a HIC
• Simplex E2724
controller-drive tray
with a HIC
An E2712 controller-drive tray or E2724 controller-drive tray attached
to DE1600 drive trays, DE5600 drive trays, or DE6600 drive trays not
to exceed a maximum of 192 drive slots or 16 total trays in the storage
array. You can mix three types of drive trays or have the following
number of drive trays in a storage array:
• 15 DE1600 drive trays with an E2712
• 14 DE1600 drive trays with an E2724
• Seven DE5600 drive trays
• Three DE6600 drive trays with an E2712 controller-drive tray
• Two DE6600 drive trays with an E2724 controller-drive tray
One of the following HICs in the controller:
• Two or four 12-Gb/s SFF-8644 mini SAS-HD connectors
• Two 10-Gb/s iSCSI RJ45 connectors
• Two or four 10-Gb/s iSCSI SFP connectors
• Two or four 16-Gb/s Fibre Channel SFP connectors
One 4-GB or one 8-GB DIMM memory for a maximum of 8-GB
capacity in the controller.
One 4-GB DIMM memory requires one 16-GB mSATA module for
controller cache backup. One 8-GB DIMM memory requires two 16-
GB mSATA modules for controller cache backup.
• Duplex E2712
controller-drive tray
with no HIC
• Duplex E2724
controller-drive tray
with no HIC
Any combination of E2700 controller-drive trays attached to DE1600
drive trays, DE5600 drive trays, or DE6600 drive trays not to exceed a
maximum of 192 drive slots or 16 total trays in the storage array. You
can mix all three types of drive trays or have the following number of
drive trays in a storage array:
• 15 DE1600 drive trays with an E2712
• 14 DE1600 drive trays with an E2724
• Seven DE5600 drive trays
• Three DE6600 drive trays with an E2712 controller-drive tray
• Two DE6600 drive trays with an E2724 controller-drive tray
One 4-GB or one 8-GB DIMM memory for a maximum of 8-GB
capacity in each controller.
One 4-GB DIMM memory requires one 16-GB mSATA module for
controller cache backup in each controller. One 8-GB DIMM memory
requires two 16-GB mSATA modules for controller cache backup in
each controller.
8 | E2700 Controller-Drive Tray and Related Drive Trays Installation Guide
