Port Type of port Function
2 Management port 1 on the
E2800 controller
1-GbE (RJ-45) Connects to the network where you access
SANtricity System Manager. You can use the
Admin Network for StorageGRID or an
independent management network.
Management port 2 on the
E2800 controller
1-GbE (RJ-45) Reserved for technical support.
3 Management port 1 on the
E5700SG controller
1-GbE (RJ-45) Connects the E5700SG controller to the Admin
Network for StorageGRID.
Management port 2 on the
E5700SG controller
1-GbE (RJ-45)
• Can be bonded with management port 1 if
you want a redundant connection to the
Admin Network.
• Can be left unwired and available for
temporary local access (IP 169.254.0.1).
• During installation, can be used to connect
the E5700SG controller to a service laptop
if DHCP-assigned IP addresses are not
available.
4 10/25-GbE ports 1-4 on the
E5700SG controller
10-GbE or 25-GbE
Note: The SFP+
transceivers included
with the appliance
support 10-GbE link
speeds. If you want to
use 25-GbE link speeds
for the four network
ports, you must provide
SFP28 transceivers.
Connect to the Grid Network and the Client
Network for StorageGRID. See "10/25-GbE
port connections for the E5700SG controller."
Steps
1. Connect the E2800 controller to the E5700SG controller, using two optical cables and four of
the eight SFP+ transceivers.
Connect this port...
To this port...
Interconnect port 1 on the E2800 controller Interconnect port 1 on the E5700SG controller
Interconnect port 2 on the E2800 controller Interconnect port 2 on the E5700SG controller
2. Connect management port 1 (P1) on the E2800 controller (the RJ-45 port on the left) to the
management network for SANtricity System Manager, using an Ethernet cable.
Do not use management port 2 (P2) on the E2800 controller (the RJ-45 port on the right). This
port is reserved for technical support.
3. If you plan to use the Admin Network for StorageGRID, connect management port 1 on the
E5700SG controller (the RJ-45 port on the left) to the Admin Network, using an Ethernet
cable.
If you plan to use active-backup network bond mode for the Admin Network, connect
management port 2 on the E5700SG controller (the RJ-45 port on the right) to the Admin
Network, using an Ethernet cable.
Hardware Installation and Maintenance Guide for SG5700 Appliances 24
Installing the hardware
