Interfaces
Rear
The following interfaces are available on the NF10WV:
NUMBER
INTERFACE
DESCRIPTION
1
Power supply jack
Connection point for the included power adapter. Connect the power supply here.
2
USB 2
Connect an external USB hard drive here to use the NAS feature of the NF10WV.
3
Reset button
Reset unit to the default factory configuration by holding the Reset button down for 7 seconds or
until all the LEDs turn off.
4
Ethernet 1 - 4
Fast Ethernet LAN ports. Connect your Ethernet based devices to one of these ports for high-
speed internet access.
5
WAN
Gigabit capable WAN port for connection to a WAN network.
6
Telephone 1 and 2
Connect a regular telephone handset here for use with a VoIP account.
7
DSL
Use the provided RJ-11 cable to connect the router to the telephone line operating your xDSL
service.
1
2
3
4
5
6
7
