HyPer 9HV IS User Manual Version 06
NetGain Motors, Inc.
Page 13 of 28
Pre-startup Steps
Download SME Smarview Sys Program:
http://www.go-ev.com/downloads/smartview_sys_dlr.zip
Download* the Latest Controller Firmware:
http://www.go-ev.com/downloads/clone_files/TAU_SYSYS_A01.D01.00A.bin
Download* Your HyPer 9HV Clone File:
http://www.go-ev.com/downloads/clone_files.html
*Not Compatible with Internet Explorer
Be sure your vehicle’s drive wheels are suspended from the ground upon initial powerup! Drive
wheels MUST NOT be in contact with any surface upon initial power up.
Controller MUST BE powered off at all times while working with the wire harness. DO NOT
adjust ampseal connectors or any wires while controller power is switched on.
Open High Voltage disconnect switch while working with High Voltage cables.
If a motor ever revs with no throttle applied, turn off the key switch immediately.
Quickstart Guide
The following number order sequence may be essential to your system and the Smartview program’s
operation. Please follow all steps carefully and in order. If a problem is encountered, ensure all steps were
followed correctly. If all steps are correct and a problem persists, please see Additional Support.
16. Follow the Wiring Diagram supplied by your dealer or shown above.
17. Fasten High Voltage Battery leads to the X144 controller’s B+ and B- terminals according to the Wiring
Diagram. This battery voltage must be within range: Minimum: 90V to Maximum: 180V.
18. Do not connect U,V,W motor leads until steps 4-18 are complete.
19. Before switching on the Controller, remove the 35pin connector.
