FS728TP Smart Switch FS728TP Smart Switch Software Administration Manual
4-20 Configuring Switching Settings
v1.0, December 2007
To view VLAN untagged port members:
1. Click Switching > VLAN > Advanced > VLAN Membership. The VLAN Membership
screen displays.
2. Click UNTAGGED PORT MEMBERS. The VLAN Untagged Ports screen opens:
Port PVID Configuration
The Port PVID Configuration screen contains parameters for assigning Port VLAN ID (PVID)
values to interfaces. All ports must have a defined PVID. If no other value is configured the default
VLAN PVID is used. VLAN ID 1 belongs to the default VLAN which cannot be deleted from the
system. Once the PVID is changed from 1 to another VLAN ID on an interface, the default VLAN
on that interface is automatically removed.
Figure 4-14
