NETGEAR GS105Ev2 User Manual

•
If you use a Mac or a 64-bit Windows-based computer, use the NETGEAR Switch
Discovery Tool to detect the IP address (see Use the NETGEAR Switch Discovery
Tool to Access the Switch on page 15).
•
If you use an iOS or Android smartphone, use the NETGEAR Insight mobile app to
detect the IP address (see Use the NETGEAR Insight Mobile App to Discover the
Switch on page 16).
•
Access the DHCP server.
•
Use an IP scanner utility.
To use your web browser to configure a switch that is connected to a network:
1. Cable the switch to a network with a router or DHCP server that manages IP
addresses.
2. Power on the switch.
The DHCP server assigns the switch an IP address.
3. Connect your computer to the same network as the switch.
4.
Determine the IP address of the switch.
By default, the DHCP client of the switch is enabled. Use the IP address that the
DHCP server assigned to the switch.
5.
Open a web browser, and enter the IP address of the switch.
The login window opens.
6. Enter the switch password.
The default password is password. The password is case-sensitive.
7.
Click the Login button.
You can now configure additional options for the switch through the local browser
interface.
For information about setting up a fixed (static) IP address for the switch, see Specify
IP Address Settings for the Switch on page 40.
User Manual11Get Started
Gigabit Ethernet Smart Managed Plus Switches

NETGEAR GS105Ev2 Specifications

General

Model	GS105Ev2
Category	Switch
Ports	5
Switching Capacity	10 Gbps
Forwarding Rate	7.4 Mpps
VLAN Support	Yes
Quality of Service (QoS)	Yes
Energy Efficient Ethernet (EEE)	Yes
Power Supply	External Power Adapter
Storage Temperature	-20° to 70° C (-4° to 158° F)
Operating Temperature	0°C to 40°C
Humidity	90% maximum relative humidity, noncondensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3az
Dimensions	6.22 x 4.02 x 1.10 in (158 x 102 x 28 mm)
Weight	0.24 kg (0.53 lb)
Jumbo Frame Support	Yes
