NETGEAR GS105Ev2 User Manual

A
Factory Default Settings
You can return the switch to its factory settings. Use the end of a paper clip or some
other similar object to press and hold the Factory Defaults button on the front panel
of the switch for at least two seconds. The switch resets and returns to the factory settings
that are shown in the following table.
Table 3. Factory default settings
SettingFeature
passwordSwitch password
192.168.0.239 (if the switch is not connected to a network with a DHCP server)IP address
255.255.255.0Subnet mask
EnabledDHCP mode
EnabledIGMP snooping
None configuredLAGs
Disabled. If enabled, by default, all ports are members of VLAN 1.VLANs
Enabled802.1p/DSCP-based QoS
DisabledPort-based QoS
DisabledRate limiting
DisabledBroadcast filtering
DisabledLoop detection
AutonegotiationPort speed
DisabledFlow control
DisabledPort mirroring
69

NETGEAR GS105Ev2 Specifications

General

Model	GS105Ev2
Category	Switch
Ports	5
Switching Capacity	10 Gbps
Forwarding Rate	7.4 Mpps
VLAN Support	Yes
Quality of Service (QoS)	Yes
Energy Efficient Ethernet (EEE)	Yes
Power Supply	External Power Adapter
Storage Temperature	-20° to 70° C (-4° to 158° F)
Operating Temperature	0°C to 40°C
Humidity	90% maximum relative humidity, noncondensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3az
Dimensions	6.22 x 4.02 x 1.10 in (158 x 102 x 28 mm)
Weight	0.24 kg (0.53 lb)
Jumbo Frame Support	Yes
