NETGEAR GS105Ev2 User Manual

ensures that the data from the computer on port 6 can be seen only by other members
of VLAN 2. You can assign only one PVID to a port.
To assign a PVID to one or more ports:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired network connection, or connect directly to a switch that
is off-network using an Ethernet cable.
2. Launch a web browser.
3.
In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch Using a Web
Browser on page 10.
The login window opens.
4. Enter the switch password.
The default password is password. The password is case-sensitive.
The Switch Information page displays.
5.
Select VLAN > 802.1Q > Advanced > VLAN Configuration.
The Advanced 802.1Q VLAN Status page displays. The menu on the left displays
more options.
6.
Select Port PVID.
You can select Port PVID only if you already enabled the advanced 802.1Q VLAN
option (see Create 802.1Q-Based VLANs in an Advanced Configuration on page
27).
The previous figure is an example. Your switch might provide more or fewer ports.
7. Select one or more ports.
8. Enter the PVID.
You can enter a PVID only for a VLAN that already exists.
9.
Click the Apply button.
Your settings are saved.
User Manual31Use VLANS for Traffic
Segmentation
Gigabit Ethernet Smart Managed Plus Switches

NETGEAR GS105Ev2 Specifications

General

Model	GS105Ev2
Category	Switch
Ports	5
Switching Capacity	10 Gbps
Forwarding Rate	7.4 Mpps
VLAN Support	Yes
Quality of Service (QoS)	Yes
Energy Efficient Ethernet (EEE)	Yes
Power Supply	External Power Adapter
Storage Temperature	-20° to 70° C (-4° to 158° F)
Operating Temperature	0°C to 40°C
Humidity	90% maximum relative humidity, noncondensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3az
Dimensions	6.22 x 4.02 x 1.10 in (158 x 102 x 28 mm)
Weight	0.24 kg (0.53 lb)
Jumbo Frame Support	Yes
