NETGEAR GS308EP User Manual

Technical specifications
This section describes the technical specifications for each switch model.
Model GS305EP and GS308EP technical specifications
The following table shows the technical specifications for models GS305EP and GS308EP.
Table 8. Models GS305EP and GS308EP technical specifications
DescriptionFeature
RJ-45 connector for 10BASE-T, 100BASE-TX, or 1000BASE-TNetwork interface
Category 5e (Cat 5e) or higher-rated Ethernet cableNetwork cable
5 for GS305EP, 8 for GS308EPEthernet ports
54V, 1.25A DC inputPower input
GS305EP: 4.9W (no PoE), 74.7W (with PoE max)
GS308EP: 6.0W (no PoE), 74.4W (with PoE max)
Power consumption
6.2 x 4.0 x 1.1 in (158 x 101 x 27 mm)Dimensions (W x D x H)
GS305EP: 0.86 lb (0.39 kg)
GS308EP: 1.08 lb (0.49 kg)
Weight
32º to 104ºF (0° to 40°C)Operating temperature
10–90% maximum relative humidity, noncondensingOperating humidity
KC Class B, FCC part 15 Class B, RCM Class B, CE Class B, VCCI Class B, BSMI,
CAN ICES-3 (B)/NMB-3(B)
Electromagnetic
compliance
CB, CE LVD, CSA, BSMISafety agency approvals
Model GS305EPP and GS308EPP technical specifications
The following table shows the technical specifications for model GS305EPP and
GS308EPP.
User Manual91Factory Default Settings and
Technical Specifications
Gigabit Ethernet Smart Managed Plus Switches Series 3XXEP and 3XXEPP

NETGEAR GS308EP Specifications

General

Model	GS308EP
Category	Switch
Ports	8
PoE Ports	8
Total PoE Budget	62W
Switching Capacity	16 Gbps
MAC Address Table Size	4K
Form Factor	Desktop
Jumbo Frame Support	Yes
VLAN Support	Yes
QoS	Yes
Energy Efficient Ethernet (EEE)	Yes
PoE Standards	IEEE 802.3af/at
Switch Type	Unmanaged
Forwarding Rate	11.9 Mpps
Operating Humidity	10% to 90% non-condensing
Operating Temperature	0 to 40°C
Power Supply	External Power Adapter
