NETGEAR Nighthawk RS400 User Manual

Manage port forwarding to a local server for
services and applications
If a server is part of your network, you can allow certain types of incoming traffic to reach
the server. For example, if your router supports such a configuration, you might want
to make a local web server, FTP server, or game server visible and available to the
Internet.
The router can forward incoming traffic with specific protocols to computers on your
local network. You can specify the servers for applications and you can also specify a
default DMZ server to which the router forwards all other incoming protocols.
Forward incoming traffic for a default service or application
You can forward traffic for a default service or application to a computer on your network.
To forward incoming traffic for a default service or application:
1.
Decide which type of service, application, or game you want to provide.
2.
Find the local IP address of the computer on your network that will provide the
service.
The server computer must always receive the same IP address. To specify this setting,
you can use the reserved IP address feature.
3.
Launch a web browser from a computer or mobile device that is connected to the
router network.
4.
Enter http://www.routerlogin.net.
A login window opens.
5. Enter the router admin user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The BASIC Home page displays.
6.
Select ADVANCED > Advanced Setup > Port Forwarding / Port Triggering.
The Port Forwarding / Port Triggering page displays.
7. Make sure that the Port Forwarding radio button is selected.
8. From the Service Name menu, select the service or application.
If the service or application that you want to add is not in the list, create a port
forwarding rule with a custom service or application (see Add a port forwarding rule
for a custom service or application on page 155).
User Manual154Manage Port Forwarding and
Port Triggering Traffic Rules
Nighthawk AC2300 Cybersecurity WiFi Router Model RS400

NETGEAR Nighthawk RS400 Specifications

General

NAT functionality	Double firewall protection (SPI and NAT)
DoS attack prevention	Yes
VPN support	Secure access to your home network away from home
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
DSL WAN	-
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1625 Mbit/s
WLAN data transfer rate (first band)	600 Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	Power
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Processor frequency	1 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Power source type	DC
Package depth	348 mm
Package width	256 mm
Package height	79 mm
Package weight	1450 g
Number of products included	1 pc(s)
Antennas quantity	3
Cables included	DC, LAN (RJ-45)
Browser supported	Internet Explorer, Microsoft Edge, Google Chrome, Firefox, Safari
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Master (outer) case width	190 mm
Master (outer) case height	298 mm
Master (outer) case length	380 mm
Master (outer) case weight	380 g

Weight and Dimensions

Depth	184.5 mm
Width	285 mm
Height	50 mm
Weight	750 g
