NETGEAR Nighthawk RS400 User Manual

10. From the Connection Mode menu, select Always On, Dial on Demand, or Manually
Connect.
11.
To change the number of minutes until the Internet login times out, in the Idle
Timeout (In minutes) field, type the number of minutes.
This is how long the router keeps the Internet connection active when no one on the
network is using the Internet connection. A value of 0 (zero) means never log out.
12. Select an Internet IP Address radio button:
•
Get Dynamically from ISP. Your ISP uses DHCP to assign your IP address. Your
ISP automatically assigns these addresses.
• Use Static IP Address. Enter the IP address, IP subnet mask, and the gateway IP
address that your ISP assigned. The gateway is the ISP router to which your router
connects.
13. Select a Domain Name Server (DNS) Address radio button:
•
Get Automatically from ISP. Your ISP uses DHCP to assign your DNS servers.
Your ISP automatically assigns this address.
•
Use These DNS Servers. If you know that your ISP requires specific servers, select
this option. Enter the IP address of your ISP’s primary DNS server. If a secondary
DNS server address is available, enter it also.
14. Select a Router MAC Address radio button:
•
Use Default Address. Use the default MAC address.
• Use Computer MAC Address. The router captures and uses the MAC address
of the computer that you are now using. You must use the one computer that the
ISP allows.
• Use This MAC Address. Enter the MAC address that you want to use.
15. Click the Apply button.
Your settings are saved.
16. Click the Test button to test your Internet connection.
If the NETGEAR website does not display within one minute, see You cannot access
the Internet on page 175.
Specify an Internet connection that uses a login and PPTP
or L2TP service
You can manually specify the connection settings for a PPTP or L2TP Internet service
for which you must log in. Use the information that your Internet service provider (ISP)
gave you to connect to your Internet service. If you cannot find this information, contact
User Manual29Specify Your Internet Settings
Nighthawk AC2300 Cybersecurity WiFi Router Model RS400

NETGEAR Nighthawk RS400 Specifications

General

NAT functionality	Double firewall protection (SPI and NAT)
DoS attack prevention	Yes
VPN support	Secure access to your home network away from home
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
DSL WAN	-
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1625 Mbit/s
WLAN data transfer rate (first band)	600 Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	Power
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Processor frequency	1 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Power source type	DC
Package depth	348 mm
Package width	256 mm
Package height	79 mm
Package weight	1450 g
Number of products included	1 pc(s)
Antennas quantity	3
Cables included	DC, LAN (RJ-45)
Browser supported	Internet Explorer, Microsoft Edge, Google Chrome, Firefox, Safari
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Master (outer) case width	190 mm
Master (outer) case height	298 mm
Master (outer) case length	380 mm
Master (outer) case weight	380 g

Weight and Dimensions

Depth	184.5 mm
Width	285 mm
Height	50 mm
Weight	750 g
