NETGEAR Nighthawk RS400 User Manual

is Up to 54 Mbps (see Change the WiFi Mbps settings on page 94). For more
information about WEP security, see Set up WEP legacy WiFi security on page
92. However, we recommend that you use WPA2-PSK [AES] security.
•
None. An open WiFi network that does not provide any security. Any WiFi device
can join the WiFi network. We recommend that you do not use an open WiFi
network because it doesn’t provide any protection.
7. Click the Apply button.
Your settings are saved.
8. Make sure that you can reconnect over WiFi to the network with its new settings.
If you cannot connect over WiFi, check the following:
•
Is your computer or mobile device already connected to another WiFi network
in your area? If so, disconnect it from that WiFi network and connect it to the WiFi
network that the router provides. Some WiFi devices automatically connect to
the first open network without WiFi security that they discover.
•
Is your computer or mobile device trying to connect to your network with its old
settings (before you changed the settings)? If so, update the WiFi network
selection in your computer or mobile device to match the current settings for
your network.
•
Does your computer or mobile device display as an attached device? If it does,
it is connected to the network.
•
Are you using the correct network name (SSID) and WiFi password?
Set up WPA/WPA2 enterprise WiFi security
WPA/WPA2 enterprise WiFi security is typically used in business settings, not in home
networks. To enable the router to provide WPA and WPA2 enterprise WiFi security, the
router must be able to access a RADIUS server. Remote Authentication Dial In User
Service (RADIUS) is an enterprise-level method for centralized Authentication,
Authorization, and Accounting (AAA) management.
Note: If your computer is connected with WiFi when you change the WiFi security
settings, you are disconnected when you click the Apply button. To avoid this problem,
use a computer with a wired connection to access the router.
User Manual90Manage the WiFi Network
Settings
Nighthawk AC2300 Cybersecurity WiFi Router Model RS400

NETGEAR Nighthawk RS400 Specifications

General

NAT functionality	Double firewall protection (SPI and NAT)
DoS attack prevention	Yes
VPN support	Secure access to your home network away from home
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
DSL WAN	-
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1625 Mbit/s
WLAN data transfer rate (first band)	600 Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	Power
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Processor frequency	1 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Power source type	DC
Package depth	348 mm
Package width	256 mm
Package height	79 mm
Package weight	1450 g
Number of products included	1 pc(s)
Antennas quantity	3
Cables included	DC, LAN (RJ-45)
Browser supported	Internet Explorer, Microsoft Edge, Google Chrome, Firefox, Safari
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Master (outer) case width	190 mm
Master (outer) case height	298 mm
Master (outer) case length	380 mm
Master (outer) case weight	380 g

Weight and Dimensions

Depth	184.5 mm
Width	285 mm
Height	50 mm
Weight	750 g
