NETGEAR Orbi RBR20 User Manual

Table 2. Orbi add-on satellite LED description
LED BehaviorLED
The Power LED is located above the Power On/Off button on the rear panel. Note: The wall
plug satellite does not include a Power LED.
•
Solid green. Power is on.
•
Solid amber. The satellite is rebooting.
•
Blinking amber. The satellite is resetting to factory default settings.
•
Blinking red. The firmware is corrupted.
•
Off. Power is not supplied.
Power LED
Optional add-on satellites are sold separately and can be added to your Orbi network. The
ring LED is located on the top.
•
Pulsing white. The satellite is booting.
•
Solid white. The satellite is ready to sync to the router (press the Sync button).
•
Blue for three minutes. The connection between the satellite and the router is good.
•
Amber for three minutes. The connection between the satellite and the router is fair.
•
Magenta. The satellite is not connected to the router or is not getting an IP address.
•
Off. The satellite synced to the router and is working normally.
Add-on satellite
ring LED
Connect your router
To cable your router:
1.
Unplug your modem’s power, leaving the modem connected to the wall jack for
your Internet service.
If your modem uses a battery backup, remove the battery.
2. Plug in and turn on your modem.
If your modem uses a battery backup, put the battery back in.
3.
Connect your modem to the Internet port of your router with the yellow Ethernet
cable that came with your router.
4. Connect the power adapter to your router and plug the power adapter into an outlet.
5.
If the Power LED does not light, press the Power On/Off button on the rear panel
of the router.
User Manual10Overview
Orbi WiFi System

NETGEAR Orbi RBR20 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
3G/4G USB modem compatibility	-
Modulation	1024-QAM
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2200 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	2
Security algorithms	WPA, WPA-PSK
Routing protocols	RIP-1, RIP-2
Data link protocols	TCP/IP, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, UPnP, SMB
Product type	Tabletop router
Product color	White
Antennas quantity	4
Processor frequency	710 MHz
Output current	1.5 A
Output voltage	12 V
AC input voltage	230 V
Power source type	AC
AC input frequency	50 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	60.96 mm
Width	142.24 mm
Height	167.64 mm
