NETGEAR Orbi RBR20 User Manual

1
Overview
The Orbi WiFi System creates dedicated high-speed WiFi connections to your Internet
service. The Orbi router connects to your modem or gateway. The Orbi satellite extends
the WiFi signal throughout your home.
This manual describes how to manage your Orbi WiFi System from your Orbi router
web interface. You can manage any add-on Orbi satellite from the Orbi router web
interface.
If you own one of the following add-on Orbi satellites, you can find more information
about your satellite from its user manual, which is available at
https://www.netgear.com/support/:
•
Orbi Outdoor Universal Satellite (model RBS50Y)
•
Orbi Voice (model RBS40V)
This chapter contains the following sections:
• LED behavior
• Connect your router
• Place your satellite
• Sync your Orbi satellite
• Set up an Ethernet backhaul connection
• Download the NETGEAR Orbi app
For more information about the topics covered in this manual, visit the support website
at https://www.netgear.com/support/.
Note: This manual refers to all Orbi router models as the router and refers to all Orbi
satellite models (including the Orbi wall plug satellite) as the satellite.
8

NETGEAR Orbi RBR20 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
3G/4G USB modem compatibility	-
Modulation	1024-QAM
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2200 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	2
Security algorithms	WPA, WPA-PSK
Routing protocols	RIP-1, RIP-2
Data link protocols	TCP/IP, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, UPnP, SMB
Product type	Tabletop router
Product color	White
Antennas quantity	4
Processor frequency	710 MHz
Output current	1.5 A
Output voltage	12 V
AC input voltage	230 V
Power source type	AC
AC input frequency	50 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	60.96 mm
Width	142.24 mm
Height	167.64 mm
