Table 4. Factory default settings for the router (Continued)
Default SettingFeature
Disabled (except traffic on port 80,
the HTTP port)
Inbound (communications coming
in from the Internet)
Firewall
Enabled (all)Outbound (communications going
out to the Internet)
DisabledSource MAC filtering
EnabledWiFi communicationWiFi
See router labelSSID name
WPA2-PSK (AES)Security
EnabledBroadcast SSID
Auto
1
Transmission speed
United States in the US; otherwise,
varies by region
Country/region
2.4GHz front and back haul: Auto
5 GHz front haul:
Channel 48 for NA, PR,AU, CA,
and TW
Channel 36 for EU, KO, JP, and
IN
5 GHz back haul:
Channel 157 for NA, PR, AU, CA,
and TW
Channel 108 for EU, KO, JP, and
IN
RF channel
1
Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual throughput can vary. Network
conditions and environmental factors, including volume of network traffic, building materials and construction, and
network overhead, lower actual data throughput rate.
Factory settings for Orbi router model RBR40
The following table shows the factory default settings for the router.
User Manual143Supplemental information
Orbi WiFi System

Table of Contents

Other manuals for NETGEAR Orbi RBR20

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR Orbi RBR20 and is the answer not in the manual?

NETGEAR Orbi RBR20 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
3G/4G USB modem compatibility-
Modulation1024-QAM
Wi-Fi bandTri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)2200 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Ethernet LAN (RJ-45) ports2
Security algorithmsWPA, WPA-PSK
Routing protocolsRIP-1, RIP-2
Data link protocolsTCP/IP, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, UPnP, SMB
Product typeTabletop router
Product colorWhite
Antennas quantity4
Processor frequency710 MHz
Output current1.5 A
Output voltage12 V
AC input voltage230 V
Power source typeAC
AC input frequency50 Hz
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 90 %
Cables includedLAN (RJ-45)
Weight and Dimensions IconWeight and Dimensions
Depth60.96 mm
Width142.24 mm
Height167.64 mm
