NETGEAR Orbi RBR20 User Manual

Table 5. Factory default settings for the router
Default SettingFeature
orbilogin.comUser login URLRouter login
adminUser name (case-sensitive)
passwordLogin password (case-sensitive)
Use default hardware addressWAN MAC addressInternet connection
1500WAN MTU size
AutoSensingPort speed
192.168.1.1LAN IPLocal network (LAN)
255.255.255.0Subnet mask
EnabledDHCP server
192.168.1.2 to 192.168.1.254DHCP range
192.168.1.2DHCP starting IP address
192.168.1.254DHCP ending IP address
DisabledDMZ
GMT for WW except NA and GR,
GMT+1 for GR, GMT-8 for NA
Time zone
DisabledTime zone adjusted for daylight
saving time
DisabledSNMP
Disabled (except traffic on port 80,
the HTTP port)
Inbound (communications coming
in from the Internet)
Firewall
Enabled (all)Outbound (communications going
out to the Internet)
DisabledSource MAC filtering
User Manual144Supplemental information
Orbi WiFi System

NETGEAR Orbi RBR20 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
3G/4G USB modem compatibility	-
Modulation	1024-QAM
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2200 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	2
Security algorithms	WPA, WPA-PSK
Routing protocols	RIP-1, RIP-2
Data link protocols	TCP/IP, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, UPnP, SMB
Product type	Tabletop router
Product color	White
Antennas quantity	4
Processor frequency	710 MHz
Output current	1.5 A
Output voltage	12 V
AC input voltage	230 V
Power source type	AC
AC input frequency	50 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	60.96 mm
Width	142.24 mm
Height	167.64 mm
