Specifications
Technical Specifications
Standards
compatibility
IEEE 802.3i 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX
Fast Ethernet, IEEE 802.3ab 1000 BASE-T, IEEE 802.3x Flow
Control, IEEE 802.1p and TOS priority, WRR queuing
Network interface RJ-45 connector for 10BASE-T, 100BASE-TX, or 1000BASE-T
Power Adapter 12V @ 1.0A DC input
Power Consumption 4W max
Weight 0.522 Kg (1.15 lbs)
Dimensions
(W x D x H)
158 mm x 105 mm x 27 mm
6.2 in x 4.1 in x 1.1 in
Operating
temperature
0 to 50°C (32 to 122°F)
Operating humidity 10% t0 90% relative humidity, non-condensing
Electromagnetic
compliance
CE Class B, included EN55022 (CISPR 22) and EN55024,
FCC part 15 Class B, VCCI Class B, C-Tick Class B
Power adapter safety
agency approvals
CE mark, Commercial UL listed (UL 60950-1), C-Tick, CB
