T
o install the utility:
1.
If necessar
y
, unzip the ReadySHARE Printer utility setup file.
2.
Double-clic
k the ReadySHARE Pr
inter utility setup file that y
ou downloaded.
3.
F
ollow the wizard instructions to install NETGEAR USB Control Center
.
After the InstallShield
Wizard completes the installation, the NETGEAR USB Control Center prompts
you to select a language
.
Share a USB Printer
129
Nighthawk A
C1750 Smar
t
WiFi Router Model R6700v2
128
130
