NETGEAR R6700v2 User Manual

Display Internet Port Statistics
To display Internet port statistics:
1. Launch a web browser from a computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Click the ADVANCED tab.
The ADVANCED Home page displays.
5. In the Internet Port pane, click the Show Statistics button.
The following information displays:
• System Up Time. The time elapsed since the router was last restarted.
• Port.The statistics for the WAN (Internet), LAN (Ethernet) ports, and WLAN (WiFi) ports. For each
port, the pop-up window displays the following information:
- Status. The link status of the port.
- TxPkts. The number of packets transmitted on the port since reset or manual clear.
- RxPkts. The number of packets received on the port since reset or manual clear.
- Collisions. The number of collisions on the port since reset or manual clear.
- Tx B/s. The number of Bytes per second transmitted on the port since reset or manual clear.
For this information, the LAN ports are treated as a single port.
- Rx B/s. The number of Bytes per second received on the port since reset or manual clear. For
this information, the LAN ports are treated as a single port.
- Up Time.The time elapsed since the port acquired the link.
- Poll Interval. The interval at which the statistics are updated in this window.
Manage the Router and Monitor the Traffic
164
Nighthawk AC1750 Smart WiFi Router Model R6700v2
