Manage the Router and Monitor the

Traffic

This chapter describes how you can manage the settings for administering and maintaining your router and

monitor the network.

The chapter includes the following sections:

• Update the Firmware of the Router on page 154

• Change the admin Password on page 156

• Set Up Password Recovery on page 157

• Recover the admin Password on page 158

• Manage the Configuration File of the Router on page 158

• Disable LED Blinking or Turn Off LEDs on page 160

• Return the Router to Its Factory Default Settings on page 160

• View the Status and Statistics of the Router on page 162

• Manage the Activity Log on page 166

• View Devices Currently on the Network on page 168

• Monitor and Meter Internet Traffic on page 170

• Manage the Router Remotely on page 175

• Remotely Access Your Router Using the genie App on page 177

153
