The user name is admin.The default password is password.The user name and password are

case-sensitive.

The BASIC Home page displays.

4. Select ADVANCED > Setup > QoS Setup.

5. Select the By Device radio button.

The following figure shows only part of the QoS Setup page.

6. Either select the radio button for a device in the MAC Device List to complete the fields automatically

(by default, each device is assigned a normal priority) or specify the settings for the device as described

in the following table.

DescriptionField

Enter a name for the QoS rule.QoS Policy for

Enter the MAC address for the device.MAC Address

Optimize Performance
