In this case, you must define a static route, instructing your router that 134.177.0.0 is accessed through
the ISDN router at 192.168.1.100. Here is an example:
• Through the destination IP address and IP subnet mask, specify that this static route applies to all
134.177.x.x addresses.
• Through the gateway IP address, specify that all traffic for these addresses is forwarded to the ISDN
router at 192.168.1.100.
• A metric value of 1 works fine because the ISDN router is on the LAN.
Set Up a Static Route
You can add a static route to a destination IP address and specify the subnet mask, gateway IP address,
and metric.
To set up a static route:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > Static Routes.
The Static Routes page displays.
5. Click the Add button.
6. To make the route private, select the Private check box.
Manage the WAN and LAN Network Settings
152
Nighthawk AC1900 Smart WiFi Router Model R6900
