NETGEAR R6900v2 User Manual

Unpack Your Router
The box contains the following items.
Figure 1. Package contents
Table 1. Legend
Router1.
Antennas (3)2.
Ethernet cable3.
Power adapter4
In some regions, a CD is included in the package.
Attach the Antennas
The router comes with three antennas.
To attach the antennas:
1. Remove the antenna caps from the antenna posts on the back panel of the router.
2. Align the antennas with the antenna posts.
Hardware Overview of the Router
10
Nighthawk AC1900 Smart WiFi Router Model R6900v2

NETGEAR R6900v2 Specifications

General

WiFi Technology	802.11ac
WiFi Performance	AC1900 (600 + 1300 Mbps)
USB Ports	1 USB 3.0 port
Antenna	3 external antennas
Processor	Dual Core 1GHz
Frequency Band	Dual Band 2.4 GHz / 5 GHz
Memory	128MB Flash, 256MB RAM
Security	Guest Network Access
Dimensions	11.22 x 7.26 x 1.97 inches
Number of Ethernet Ports	5 x 10/100/1000 Mbps Gigabit Ethernet ports (1 WAN & 4 LAN)
