NETGEAR R6900v2 User Manual

• Reset button. For information about using the Reset button, see Return the Router to Its Factory Default
Settings on page 160.
• Ethernet LAN ports. Use the four Gigabit Ethernet RJ-45 LAN ports to connect the router to LAN
devices.
• WAN port. Use the yellow Gigabit Ethernet RJ-45 WAN port to connect the router to a modem.
• Power On/Off button. Press the Power On/Off button to provide power to the router.
• DC power connector. Connect the power adapter that came in the product package to the DC power
connector.
USB Port on the Front Panel
A USB 3.0 port is located on the front of the router.
Figure 3. USB 3.0 port
Hardware Overview of the Router
13
Nighthawk AC1900 Smart WiFi Router Model R6900v2

NETGEAR R6900v2 Specifications

General

WiFi Technology	802.11ac
WiFi Performance	AC1900 (600 + 1300 Mbps)
USB Ports	1 USB 3.0 port
Antenna	3 external antennas
Processor	Dual Core 1GHz
Frequency Band	Dual Band 2.4 GHz / 5 GHz
Memory	128MB Flash, 256MB RAM
Security	Guest Network Access
Dimensions	11.22 x 7.26 x 1.97 inches
Number of Ethernet Ports	5 x 10/100/1000 Mbps Gigabit Ethernet ports (1 WAN & 4 LAN)
