NETGEAR R6900v2 User Manual

7. Click the Add button.
8. Specify the settings as described in the following table.
DescriptionField
Enter a name for the VLAN tag group.
The name can be up to 10 characters.
Name
Enter a value from 1 to 4094.VLAN ID
Enter a value from 0 to 7.Priority
Select the check box for a wired LAN port or WiFi port.
If your device is connected to an Ethernet port on the router, select the LAN port check box that corresponds
to the Ethernet port on the router to which the device is connected. If your device is connected to your router’s
WiFi network, select the WiFi check box that corresponds to the router’s WiFi network to which the device
is connected.
You must select at least one LAN port or WiFi port.You can select more than one port.
9. Click the Add button.
The VLAN tag group is added.
10. Click the Apply button.
Your settings are saved.
Manage the WAN and LAN Network Settings
152
Nighthawk AC1900 Smart WiFi Router Model R6900v2

NETGEAR R6900v2 Specifications

General

WiFi Technology	802.11ac
WiFi Performance	AC1900 (600 + 1300 Mbps)
USB Ports	1 USB 3.0 port
Antenna	3 external antennas
Processor	Dual Core 1GHz
Frequency Band	Dual Band 2.4 GHz / 5 GHz
Memory	128MB Flash, 256MB RAM
Security	Guest Network Access
Dimensions	11.22 x 7.26 x 1.97 inches
Number of Ethernet Ports	5 x 10/100/1000 Mbps Gigabit Ethernet ports (1 WAN & 4 LAN)
