NETGEAR SRK60B04 User Manual

If your browser does not display a login window but displays a security warning and
does not let you proceed, see Resolve a browser security warning on page 27.
3. Enter the admin user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The BASIC Home page displays.
4.
Select ADVANCED > Advanced Setup > VLAN / Bridge Settings.
The VLAN / Bridge Settings page displays.
5.
Select the Enable VLAN/Bridge Group check box.
The page expands.
6.
Select the By VLAN Profile radio button.
The section expands.
7. Click the Add button.
The Add VLAN Profile Rule page displays.
8.
Specify the settings as described in the following table.
DescriptionField
This menu is set to Others and you cannot change it.ISP Profile
Enter a name for the VLAN profile.
The name can be up to 16 characters.
Name
Enter a value from 1 to 4094.VLAN ID
Enter a value from 0 to 7.Priority
Select the check box for a wired Ethernet port.
If your device is connected to an Ethernet port on the router, select the Ethernet port check box that
corresponds to the Ethernet port on the router to which the device is connected.
You must select at least one Ethernet port. You can select more than one port.
9. Click the Apply button.
The VLAN profile is added.
10. Click the Apply button.
Your settings are saved.
User Manual117Manage the LAN, WAN, and
WiFi Settings
Orbi Pro Router Model SRR60 and Orbi Pro Satellite Model SRS60

NETGEAR SRK60B04 Specifications

General

Brand	NETGEAR
Model	SRK60B04
Category	Network Router
Language	English
