View or change WAN settings
You can view or configure wide area network (WAN) settings for the Internet port. You
can set up a DMZ (demilitarized zone) server, change the maximum transmit unit (MTU)
size, and enable the router to respond to a ping to its WAN (Internet) port.
To view the WAN settings:
1.
Launch a web browser from a computer or mobile device that is connected to your
Orbi network.
2. Enter orbilogin.com.
A login window displays.
If your browser does not display a login window but displays a security warning and
does not let you proceed, see Resolve a browser security warning on page 27.
3. Enter the admin user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Setup > WAN Setup
The WAN Setup page displays.
5.
View or change the following settings:
•
Disable Port Scan and DoS Protection. DoS protection protects your LAN against
denial of service attacks such as Syn flood, Smurf Attack, Ping of Death, and many
others. Select this check box only in special circumstances.
•
Default DMZ Server. This feature is sometimes helpful when you are playing
online games or videoconferencing, but it makes the firewall security less effective.
See Set up a default DMZ server on page 73.
•
Respond to Ping on Internet Port. This feature allows your router to be
discovered. Use this feature only as a diagnostic tool or if you have a specific
reason.
•
Disable IGMP Proxying. IGMP proxying allows a client on the LAN or a WiFi
network to receive the multicast traffic it is interested in from the Internet. By
default, IGMP proxying is disabled. If you clear the check box, IGMP proxying is
User Manual69Manage the LAN, WAN, and
WiFi Settings
Orbi Pro Router Model SRR60 and Orbi Pro Satellite Model SRS60
