NETGEAR WG511T User Manual

User Manual for the NETGEAR 108 Mbps Wireless PC Card 32-bit CardBus WG511T
Basic Setup 3-13
Interpreting System Tray Icon Colors
The System Tray (SysTray) resides on one end of the taskbar in the Microsoft Windows desktop.
Color Condition Description
Red
The wireless PC Card has
no connection to any
other wireless node.
The wireless PC Card is not able to link to any other
wireless node or the link is lost. Check your
configuration or try moving to a location where the
wireless signal quality is better.
Yellow
The wireless PC Card has
a connection with another
wireless node.
The wireless link is weak. You may deed to move to a
better spot, such as closer to the wireless access point.
Also, look for possible interference such as a 2.4 GHz
cordless phone or large metal surface.
Green
The wireless PC Card has
a connection with another
wireless node.
The wireless PC Card has established good
communication with an access point and the signal
quality is strong.

NETGEAR WG511T Specifications

Radio Specifications

radio data rate	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps and 108 Mbps in turbo mode
frequency US	2.412 ~ 2.462 GHz
frequency Japan	2.412 ~ 2.484 GHz
frequency Europe ETSI	2.412 ~ 2.472 GHz
frequency Spain	2.457 ~ 2.462 GHz
frequency France	2.457 ~ 2.472 GHz

Security

encryption	40-bit (also called 64-bit) and 128-bit WEP Encryption
electromagnetic compliance	FCC Part 15 Sub Class B
modulation type	OFDM with BPSK, QPSK, 16QAM, 64QAM, DBPSK, DQPSK, CCK

Physical Specifications

dimensions	119 x 54 x 6 mm (4.68 x 2.12 x .25 in.)
weight	46 g (1.6 oz)
warranty	NETGEAR 1-year warranty
