NETGEAR WG511T User Manual

User Manual for the NETGEAR 108 Mbps Wireless PC Card 32-bit CardBus WG511T
Configuration 4-7
3. Configure the PC network settings.
a. Configure each PC with either a static IP address or with the IPX protocol.
Note: For instructions on configuring static IP addresses, refer to the networking tutorial
on your NETGEAR 108 Mbps Wireless PC Card WG511T Resource CD (SW-10036-01).
b. Restart the PCs.
4. Verify wireless connectivity between your peer devices.
Verify connectivity by using the Ping program:
a. On the Windows taskbar click the Start button, and then click Run.
b. Assuming the target PC is configured with 192.168.0.1 as its IP address, type ping -t
192.168.0.1
and then click OK.
c. This will cause a continuous ping to be sent to the device with the 192.168.0.1 static IP
address. The ping response should change to “reply.”
At this point the connection is established.
You may need to reboot in certain Windows operating systems such as Windows 98.
Note: If you cannot connect, see the “Troubleshooting” on page 3-14. Also, for problems with
accessing network resources, the Windows Client and File and Print Sharing software might
not be installed and configured properly on your computers. Please refer to “Preparing Your
Computers for TCP/IP Networking” on page C-1.

NETGEAR WG511T Specifications

Radio Specifications

radio data rate	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps and 108 Mbps in turbo mode
frequency US	2.412 ~ 2.462 GHz
frequency Japan	2.412 ~ 2.484 GHz
frequency Europe ETSI	2.412 ~ 2.472 GHz
frequency Spain	2.457 ~ 2.462 GHz
frequency France	2.457 ~ 2.472 GHz

Security

encryption	40-bit (also called 64-bit) and 128-bit WEP Encryption
electromagnetic compliance	FCC Part 15 Sub Class B
modulation type	OFDM with BPSK, QPSK, 16QAM, 64QAM, DBPSK, DQPSK, CCK

Physical Specifications

dimensions	119 x 54 x 6 mm (4.68 x 2.12 x .25 in.)
weight	46 g (1.6 oz)
warranty	NETGEAR 1-year warranty
