4-1
v1.1, May 2008
Chapter 4
Customizing Your Network Settings
This chapter describes how to configure advanced networking features of the
Wireless-G Router Model WGR614v8, including LAN, WAN, and routing settings.
It contains the following sections:
• “Using the LAN IP Setup Options” on page 4-1”
• “Using a Dynamic DNS Service” on page 4-4
• “Configuring the WAN Setup Options” on page 4-6
• “Configuring Static Routes” on page 4-8
• “Wireless Repeating (Also Called WDS)” on page 4-10
Using the LAN IP Setup Options
The LAN Setup screen allows configuration of LAN IP services such as Dynamic Host
Configuration Protocol (DHCP) and Routing Information Protocol (RIP).
To configure LAN IP settings, from the main menu of the browser interface, under Advanced,
click LAN Setup. The following screen displays:
.
Figure 4-1
