NETGEAR WN3100RP User Manual

Get Started
12
N300 WiFi Range Extender
The first time that you log in to the extender, the Create Account screen displays. If the
Create Account screen does not display, go to www.mywifiext.net.
4. Complete the fields and click the NEXT button.
5. When prompted, select your country or region from the Regional Settings menu and click
the NEXT button.
6. Click the WIFI RANGE EXTENDER button.
The extender scans for WiFi signals and finds the WiFi networks in your area and
displays a list.
7. Select a WiFi network to extend and click the NEXT button.
If your existing WiFi network is hidden, select the Manually input my wireless SSID
radio button and type your WiFi network name.
You are prompted to enter the password for the WiFi network that you selected.
8. T
ype the WiFi network password (also called passphrase or security key) in the Password
(Network Key) field and click the NEXT button.
9. Set the network name (SSID) and password for your new extender WiFi network and click
the NEXT button.
The extender connects to your existing WiFi network. You are prompted to connect your
computers and WiFi devices to the extender network.
10. Use a WiFi network manager on the computer or WiFi device to connect to the new
extended WiFi network.

NETGEAR WN3100RP Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Product color	White
Bandwidth	2.4 GHz
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA2-PSK, WPS
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	32.5 mm
Width	55 mm
Height	114 mm
Weight	175 g
