NETGEAR WN3100RP User Manual

Extender Network Settings
25
N300 WiFi Range Extender
Use WPS with the Push Button Method
To use the push button method to connect a WiFi device to the extender’s WiFi network, the
WiFi device that you are trying to connect must have a physical button or a software button.
 To use WPS to add a computer or WiFi device to the extender’s WiFi network:
1. On a computer or WiFi device that is connected to the extender network, launch a web
browser
.
2. In the address field of your browser
, enter www.mywifiext.net.
You are prompted to enter a user name and password.
3. Enter your email address and password.
4. Click the Menu icon
.
The extender menu displays.
5. Select Settings > Do More > Connect Devices (WPS).
6. Leave the Push Button (recommended) radio button selected.
7. Click the WIFI PROTECTED SETUP (WPS) button.
The WPS LED
blinks green for two minutes.
For two minutes, the extender attempts to add the computer or WiFi device to its WiFi
network.
8. Within two minutes, go to the computer WiFi device and press or click its WPS button.
9. T
o verify that the WiFi device is connected to the extender’s WiFi network, select
Settings > Connected Devices.
The WiFi device displays onscreen.
Use WPS with the PIN Method
To use the PIN method to connect a WiFi device to the extender’s WiFi network, you must
know the PIN of the WiFi device that you are trying to connect.

NETGEAR WN3100RP Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Product color	White
Bandwidth	2.4 GHz
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA2-PSK, WPS
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	32.5 mm
Width	55 mm
Height	114 mm
Weight	175 g
