NETGEAR WN3100RP User Manual

Extender Network Settings
30
N300 WiFi Range Extender
Set Up the Extender to Use a Static IP Address
The extender comes set up to use a dynamic IP address, which is the correct setting for most
home networks.
 To set up the extender to use a static IP address:
1. On a computer or WiFi device that is connected to the extender network, launch a web
browser
.
2. In the address field of your browser
, enter www.mywifiext.net.
You are prompted to enter a user name and password.
3. Enter your email address and password.
4. Click the Menu icon
.
The extender menu displays.
5. Select Settings > W
ireless Settings.
The WiFi Settings screen displays.
6. Scroll to the IP
Address section.
By default, the Dynamically get IP
Address from Router radio button is selected.
7. Select the Use Static IP
Address radio button.
8. Complete the fields to specify the IP network IP addresses.
9. Click the SA
VE button.
Your settings are saved.

NETGEAR WN3100RP Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Product color	White
Bandwidth	2.4 GHz
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA2-PSK, WPS
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	32.5 mm
Width	55 mm
Height	114 mm
Weight	175 g
