NETGEAR WN3100RP User Manual

Maintain and Monitor the Extender
34
N300 WiFi Range Extender
Automatically Adjust for Daylight Saving Time
 To set up the extender to automatically adjust for daylight saving time:
1. On a computer or WiFi device that is connected to the extender network, launch a web
browser
.
2. In the address field of your browser
, enter www.mywifiext.net.
You are prompted to enter a user name and password.
3. Enter your email address and password.
4. Click the Menu icon
.
The extender menu displays.
5. Select Do More >
Access Schedule.
The Access Schedule screen displays.
6. Select the Automatically adjust for daylight saving time check box.
7. Click the SA
VE button.
Your settings are saved.
Manually Set the Extender Clock
 To manually set the extender clock:
1. On a computer or WiFi device that is connected to the extender network, launch a web
browser
.
2. In the address field of your browser
, enter www.mywifiext.net.
You are prompted to enter a user name and password.
3. Enter your email address and password.
4. Click the Menu icon
.
The extender menu displays.
5. Select Do More >
Access Schedule.
The Access Schedule screen displays.
6. In the Extender Clock section, select the Manual radio button.
7. T
o specify the time, complete the fields or click the Sync Clock link to synchronize the
extender time to the time on the computer or WiFi device that you are using.
The Day field and T
ime field display the time.
8. Click the SA
VE button.
Your settings are saved.

NETGEAR WN3100RP Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Product color	White
Bandwidth	2.4 GHz
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA2-PSK, WPS
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	32.5 mm
Width	55 mm
Height	114 mm
Weight	175 g
