NETGEAR WN3100RP User Manual

Get Started
16
N300 WiFi Range Extender
9. Click the ACCESS POINT button.
The extender checks for an Internet connection through the router that you connected to
the extender
.
10. Set the network name (SSID), security option, and password, and click the NEXT button.
Your settings are applied and the extender is ready to be used as an access point.
11. Use a WiFi network manager on the computer or WiFi device to connect to the new access
point network.
12. Repeat this step for all of your computers and WiFi devices.
13. Click the CONTINUE button.
A screen displays that says you successfully created an access point.
14. Click the NEXT button.
The registration screen displays.
15. Complete the registration fields and click the FINISH button to complete the setup.
If you do not want to register your extender, click the Skip Registration link. Note that
you must register your extender before you can use NETGEAR telephone support.
The Status screen displays.
Log In to the Extender After Installation
You can log in to the extender to view or change the extender’s settings.
 To log in to the extender:
1. Use a WiFi network manager on a computer or WiFi device to find and connect to the
new extended WiFi network.
After the connection with the computer or WiFi device is established, the Client Link LED
lights solid green.
2. Launch a web browser
.
3. Enter www
.mywifiext.net in the address field of the browser.
A login screen displays.
4. Enter your email address and password and click the LOG IN button.
The Status screen displays.

NETGEAR WN3100RP Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Product color	White
Bandwidth	2.4 GHz
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA2-PSK, WPS
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	32.5 mm
Width	55 mm
Height	114 mm
Weight	175 g
