NETGEAR WN3100RP User Manual

Get Started
15
N300 WiFi Range Extender
 To use the extender in access point mode:
1. Plug the extender into an electrical outlet.
2. W
ait for the Power LED to light amber and then turn green.
If the Power LED does not light, slide the Device On/Off switch on the side of the
extender to the On position.
3. Use an Ethernet cable to connect the extender to the router Ethernet LAN port or the remote
Ethernet LAN jack with LAN access.
The extender joins the LAN and creates a WiFi hotspot.
4. Use a WiFi network manager on a computer or WiFi device to find and connect to the
NETGEAR_EXT (SSID) WiFi network.
After the connection with the computer or WiFi device is established, the Client Link LED
lights.
5. Launch a web browser and enter www
.mywifiext.net in the address field.
A login screen displays.
6. Click the NEW EXTENDER SETUP button.
The first time that you log in to the extender, the Create Account screen displays. If the
Create
Account screen does not display, visit www.mywifiext.net.
7. Complete the fields and click the NEXT button.
You are prompted to select your region.
8. Select your country or region from the Regional Settings menu and click the NEXT button.

NETGEAR WN3100RP Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Windows operating systems supported	Yes
Product color	White
Bandwidth	2.4 GHz
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA2-PSK, WPS
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	32.5 mm
Width	55 mm
Height	114 mm
Weight	175 g
