Advanced Settings
91
N600 Wireless Dual Band Gigabit Router Premium Edition WNDR3800
Wireless repeating is a type of Wireless Distribution System (WDS). A WDS allows a wireless
network to be expanded through multiple access points instead of using a wired backbone to
link them. The following figure shows a wireless repeating scenario.
Repeater
Base station
access point
access point
Figure 9. Wireless repeating scenario
Note: If you use the wireless repeating function, you need to select either
WEP or None as a security option in the Wireless Settings screen.
The WEP option displays only if you select the wireless mode Up to
54Mbps in the Wireless Settings screen.
Wireless Base Station. The router acts as the parent access point, bridging traffic to and
from the child repeater access point, as well as handling wireless and wired local computers.
To configure this mode, you have to know the MAC addresses of the child repeater access
point.
Wireless Repeater. The router sends all traffic from its local wireless or wired computers to a
remote access point. To configure this mode, you have to know the MAC address of the
remote parent access point.
The WNDR3800 router is always in dual band concurrent mode, unless you turn off one
radio. Be aware that if you enable the wireless repeater in either radio band, the wireless
base station or wireless repeater cannot be enabled in the other radio band. However, if you
