XAV101 Powerline AV Ethernet Adapter User Guide
2-12 Using the XAV101 Configuration Utility
v1.0, April 2008
2. Select the QoS (Quality of Service) tab.
3. Specify the priority in the Configure Advanced QoS Settings section of the screen:
4. To set the traffic prioritization rule into the selected Powerline AV Ethernet Adapter device,
click Apply.
These options only apply to QoS-configured business networks. IEEE 802.1p uses prioritization
bits in Layer-2 frames. Type of Service routing (ToS) uses prioritization bits in Layer-3 IP packets.
The deprecated ToS values range from 0 to 7.
Figure 2-10
Note: QoS settings are applied to only the device that is selected on the QoS tab.
