XAV101 Powerline AV Ethernet Adapter User Guide
1-2 Installation and Basic Configuration
v1.0, April 2008
How the Powerline AV Ethernet Adapter Fits in Your Network
You can use Powerline AV Ethernet Adapters to extend your Ethernet network anywhere in your
house using your existing electrical power line. The following figure shows an example of a
Powerline network with two Powerline devices. The Powerline network connects to an Ethernet
network:
Figure 1-1
Internet
Router
Ethernet network
Ethernet network
XAV101
XAV101
Powerline network
(always encrypted)
Notebook PC
Desktop PC
