Getting Started
10
Powerline PassThru Adapter
XAV6504 Powerline 600 PassThru Four-Port Adapter
The hardware features of the XAV6504 adapter are shown in the following figure.
Factory Reset
button
Security
button
Filtered AC Ethernet LED
Power
LED
Powerline LED
Gigabit
Ethernet port
Ethernet LED On/Off
socket
switch
Ethernet
port
Figure 5. XAV6504 hardware features
