Supplemental Information
38
Powerline PassThru Adapter
XAV5401 Technical Specifications
The XAV5401 adapter meets the technical specifications defined in the following table.
Table 3. XAV5401 technical specifications
Feature Specification
Data and routing protocols IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx)
AC input 100–240V, 0.2A (max.)
Socket outlet rating (max. load) AU: 10A, 250V; EU: 16A, 250V; NA: 15A, 125V; UK: 13A, 250V;
Power consumption Normal: 4W, Power saving mode: <0.5W
Dimensions 114 x 55 x 32.5 mm (4.49 x 2.17 x 1.28 in)
Weight 0.174 kg (0.384 lb)
Operating temperature 0° to 40°C (32º to 104ºF)
Operating humidity 10–90% maximum relative humidity, noncondensing
Storage humidity 5–95% maximum relative humidity, noncondensing
Security encryption type 128-bit AES
MAC addresses 8 (active) / 16 (total): number of nodes that can be added to a
single network
Bandwidth 500 Mbps
Compatibility HomePlug AV IEEE 1901
(Not compatible with HomePlug v1.0 or HomePlug v1.0 Turbo)
Data transfer rate Up to 500 Mbps with real throughput greater than 80 Mbps
Frequency band 2–75 Mbps
Modulation type OFDM symbol modulation
Electromagnetic emissions CE-EMC Class B
Safety agency approvals IEC60950; CE LVD
