Getting Started
9
Powerline PassThru Adapter
XAV6501 Powerline 600 PassThru One-Port Adapter
The hardware features of the XAV6501 adapter are shown in the following figure.
Factory Reset
button
Security
button
Filtered AC Ethernet LED
Power
LED
Powerline LED
Gigabit
Ethernet port
Ethernet LED On/Off switch
socket
Figure 4. XAV6501 hardware features
