NETGEAR XS728T User Manual

Hardware Overview
15
ProSAFE 28-Port and 48-Port 10-Gigabit Smart Managed Switch Models XS728T and XS748T
Switch Hardware Interfaces
The following sections describe the hardware interfaces on the switch.
1G/10G RJ-45 Ports
All copper RJ-45 ports support AutoSensing. When you insert a cable into an RJ-45 port, the
switch automatically ascertains the maximum speed (1 Gbps or 10 Gbps) and duplex mode
(half-duplex or full-duplex) of the attached device. All ports support a Category 5e (Cat 5e)
unshielded twisted-pair (UTP) cable or higher rated Ethernet cable terminated with an 8-pin
RJ-45 connector.
To simplify the procedure for attaching devices, all RJ-45 ports support Auto Uplink. This
technology allows attaching devices to the RJ-45 ports with either straight-through or
crossover cables.
Note: For 10GBASE-T ports, Ethernet specifications limit a Category 6
(Cat 6) cable length between the switch and the attached device to
328 feet (100 meters).
When you insert a cable into the switch’s RJ-45 port, the switch automatically performs the
following actions:
• Senses whether the cable is a straight-through or crossover cable.
• Determines whether the link to the attached device requires a normal connection (such
as when you are connecting the port to a computer) or an uplink connection (such as
when you are connecting the port to a router, switch, or hub).
• Automatically configures the RJ-45 port to enable communications with the attached
device. The Auto Uplink technology compensates for setting uplink connections while
eliminating concern about whether to use crossover or straight-through cables when you
attach devices.
Speed/ACT LEDs for SFP+
slots 45 to 48
Green LED (10G LED)
• Off . No SFP+ module is inserted or no module link is established.
• Solid green . A valid 10 Gbps link is established.
• Blinking green. The module is transmitting or receiving packets at 10 Gbps.
Yellow LED (1G LED)
• Off . No SFP+ module is inserted or no module link is established.
• Solid yellow . A valid 1 Gbps link is established.
• Blinking yellow. The module is transmitting or receiving packets at 1 Gbps.
Table 2. Port and system LEDs model XS748T (continued)
LED Designation

NETGEAR XS728T Specifications

General

Model	XS728T
Ports	28
10GBase-T Ports	24
SFP+ Ports	4
Switching Capacity	560 Gbps
Form Factor	Rack-mountable
Layer	Layer 3
Management	Yes
Weight	18.5 lbs
Total Number of Network Ports	28
Uplink Port	Yes
Ethernet Technology	10 Gigabit Ethernet
Number of Total Expansion Slots	4
Number of SFP+ Slots	4
Manageable	Yes
Width	440 mm
Forwarding Rate	417 Mpps
Power Supply	Internal
MAC Address Table Size	32K
Jumbo Frame Support	Yes
Humidity	10% to 90% non-condensing
Product Type	Switch
Media Type Supported	Twisted Pair, Optical Fiber
Layer Supported	Layer 3
Power Source	AC
Height	43.2 mm
Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Latency (10G)	1.5 μs
