Supplemental Information
41
Powerline 500 WiFi Access Point (XWN5001)
Technical Specifications
Feature Specification
Data and routing protocols IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx)
AC input 100–240V, 0.2A (max.)
Power consumption Normal: 4W, Power saving mode: 3W
Dimensions 112 x 74 x 45 mm (4.41 x 2.91 x 1.77 in.)
Weight 0.245 kg (0.54 lb)
Socket ratings EU: 15A 250V
NA: 14A 125V
UK: 12A 250V
Operating temperature 0 to 40C (32º to 104ºF)
Operating humidity 10–90% maximum relative humidity, noncondensing
Storage humidity 5–95% maximum relative humidity, noncondensing
Security encryption type 128-bit AES
MAC addresses 64: number of nodes that can be added to a single network
Bandwidth 200 Mbps
Compatibility Not HomePlug v1.0 or HomePlug v1.0 Turbo compatible
Data transfer rate Up to 200 Mbps with real throughput greater than 80 Mbps
Frequency band 2–30 Mbps
Modulation type OFDM symbol modulation
Electromagnetic emissions FCC Part 15 Class B; CE-EMC Class B; 3-home FCC Certificate
Safety agency approvals UL Listed (UL 1950) /cUL IEC950; CE LVD; TUV CB, TUV CG
Wireless Wireless communication Enabled
Wireless Network Name
(SSID)
Security
Transmission speed Auto
a
a. Maximum wireless signal rate (IEEE Standard 802.11). Actual throughput will vary. Network conditions
and environmental factors, including volume of network traffic, building materials and construction, and
network overhead, lower actual data throughput rate.
Country/Region United States (varies by region)
Operating mode 802.11n, 802.11g, 802.11b
Data rate Up to 300 Mbps
