15
II. INSTALLATION AND CONFIGURATION
II. 1. Connecting the equipment
II. 1. 1. Adapter configuration
Adapter must be configured before it is used. Adapter contains own configuration
software and it can be configured locally only.
Adapter configuration
Adapter contains a configuration software that can be accessed by connecting the
Adapter to computer with running emulation software (TES). When configuration is complete,
disconnect the Adapter from the terminal and install it to your network.
To use the built-in software for Network Adapter configuration you need a terminal
with RS-232 serial port, or a PC with terminal emulation software for example Windows
Terminal. Set the serial link to 9600 baud, No parity, 8 data bits, 1 stop bit, no control flow.
NOTE : Configuration software is always activated with this setting, even you change the
adapter`s serial configuration.
Connecting the adapter to terminal and starting the configuration software :
1. Connect the serial cable to the Network Adapter`s configuration port and
to the serial port on terminal
2. Connect power supply for Network Adapter
3. Wait for about 10 seconds, then press Enter and the main configuration menu is displayed
If the main configuration menu is not displayed, interrupt power supply to Network
Adapter and repeat steps 2 and 3. If the main configuration menu is still not displayed, check
the following conditions :
• check the communication settings on the terminal you are using. It must be set to 9600
baud, No parity, 8 data bits, 1 stop bit, no control flow.
• if the serial link configuration is correct, check the cables and plugs
• repeat steps 2 and 3. If the main configuration menu is not displayed even after these steps,
please, contact the factory or your distributor for help.
