Ping: Slide the toggle switch right to run an ICMP
Ping test to the target address test. The Port field
disappears when this toggle is enabled.
+ ADD TARGET: Touch to add additional target
address fields.
VLAN
Enable VLAN: Slide the toggle to the right to
enable VLAN settings. Once enabled, VLAN ID and
VLAN Priority fields appear. Touch these fields to
open a pop-up number pad and enter the correct
ID and priority. Touch OK to save them.
User Defined MAC
Enable User Defined MAC: Slide the toggle to the
right to enable a user-defined MAC address. When
enabled, the User Defined MAC field turns from
grey to black.
User Defined MAC: If enabled, touch this field to
open a pop-up keyboard and enter your MAC
address. Touch OK to save it.
General Settings
Cable Unit: Touch the down caret to select
either meters or feet for the Cable Test unit of
39
LinkRunner G2 Application Settings
