5.2 Appendix C – Analyzer Factory Configuration Settings
Alarm and Relay Setup Information
Alarm-1/Alarm-2 Relays Failsafe/Non-Failsafe
NON-FAILSAFE
Alarm-1/Alarm-2 Relay Ascending/Descending
ASCENDING
Alarm-1 Trigger Level
5 %
Alarm-2 Trigger Level
10 %
Display Range Analog Voltage Output
0–1 % Fixed
0–1 VDC
X
0–10 % Fixed
0–5 VDC
0–25 % Fixed
0–10DC
0–50 % Fixed
0–100 % Fixed
Relay Disable after
Cal/Setup
Low Auto Ranging
120-seconds
X
High Auto Ranging
Full Auto Ranging
X
Rs-232 Baud Rate Assume Low End Calibration Range
300 BPS
Single Point
1200 BPS
1–5 %
X
2400 BPS
1–50 %
4800 BPS
18–24 %
9600 BPS
X
19200 BPS
38400 BPS
Rs-232 Output Format
Output on Request Only
Human Readable Format
X
Machine Code
Machine Code With Checksum
Tab Delimited (Spreadsheet)
Supply Voltage RS-232 Dump Rate
90 – 264 VAC, 47 – 63 Hz
X
1-second
X
11 – 30 VDC
